限位开关系列主要技术指针Specifications of Main Technical Performances Switch series

使用温度范围Temperature

-40-70 ^oC

耐压Withstand Voltage

AC250V(50Hz)/min

额定负荷Rated load

0.2A60VDC

动作力Actuating Force

20-35g

接触电阻Contact Resistance

<0.02Ω

寿命Life

1000000次

绝缘电阻Insulation Resistance

>100MΩ
