AC电源插座系列主要技术指标Specification of AC power jack serie

使用温度范围Temperature

-30~70℃

耐压Withstanf Voltage

AC1500V（50HZ）1min

额定负荷Rated load

AC250v10A

插拔力Insertion and Extraction Force

3-20N

接触电阻Contact Resistance

≤0.1Ω

寿命life

5000 次

绝缘电阻Insulation Resistance

≥100ΜΩ
